Mattress Tape Edge Sewing Machine 1.8*2.0m

Model NO.	WB-3
Condition	New
Automatic Grade	Full-Automatic
Thread Number	Single-Thread
Sewing Head Number	Single-Head
Sewing Head Type	Lock Stitch
Sewing Thickness Range of Mattress	20-350mm
Table Lifting Range	280mm
Working Angle of The Sewing Head	60°
Power Supply	Single-Phase,220V,50Hz
Size of The Working Table	2000*1500
Machine Size	21001600800
Total Power	1.15kw
Transport Package	Wooden Packing
Specification	21001600800
Trademark	Qinyuan
Origin	China

Parameter	WB-1	WB-2	WB-3	WB-4
Sewing thickness range of mattress	20-350MM	20-350MM	20-350MM	20-350MM
Table lifting range	260mm	260mm	280mm
Working angle of the sewing head	40°	60°	60°	25°65°
Power supply	single-phase,220v,50Hz	single-phase,220v,50Hz	single-phase,220v,50Hz	single-phase,220v,50Hz
Size of the working table	1920*1500	2000*1500	2000*1500	3850*1980
Machine size	21301600800	21001600800	21001600800	242024001880
Total power	400W	1.15KW	1.15kw	3KW
Total weight	400kg	425Kg	550Kg	1500Kg
Productivity	15PCS/H	20PCS/H	20PCS/H	16-20PCS/H
